  HOME>>PRODUCTS>>Digital Caliper Series>>Digital depth gages ::::....... BACK>>


Features

Power on/off.
Inch/mm conversion at any position.
Zero-setting at any position.
Data output.
Technology Parameter
Measuring Range Order No Resolution Accuracy L mm a mm b mm d mm
0-150mm(0-6″) K21-101 0.01mm(.0005″) ±0.03mm 230 100 8.5 14.5
　 K21-101-1 0.01mm(.0005″) ±0.03mm 230 150 8.5 14.5
0-200mm(0-8″) K21-102 0.01mm(.0005″) ±0.03mm 280 100 8.5 14.5
　 K21-102-1 0.01mm(.0005″) ±0.03mm 280 150 8.5 14.5
0-250mm(0-10″) K21-103 0.01mm(.0005″) ±0.04mm 330 100 8.5 14.5
　 K21-103-1 0.01mm(.0005″) ±0.04mm 330 150 8.5 14.5
0-300mm(0-12″) K21-104 0.01mm(.0005″) ±0.04mm 380 100 8.5 14.5
　 K21-104-1 0.01mm(.0005″) ±0.04mm 380 150 8.5 14.5
0-500mm(0-20″) K21-105 0.01mm(.0005″) ±0.05mm 580 120 7 15
　 K21-105-1 0.01mm(.0005″) ±0.05mm 580 150 7 15
　 K21-105-2 0.01mm(.0005″) ±0.05mm 580 200 7 15
0-600mm(0-24″) K21-106 0.01mm(.0005″) ±0.06mm 680 120 7 15
　 K21-106-1 0.01mm(.0005″) ±0.06mm 680 150 7 15
　 K21-106-2 0.01mm(.0005″) ±0.06mm 680 200 7 15
0-800mm(0-32″) K21-107 0.01mm(.0005″) ±0.07mm 988 150 7 18
　 K21-107-1 0.01mm(.0005″) ±0.07mm 988 200 7 18
　 K21-107-2 0.01mm(.0005″) ±0.07mm 988 250 7 18
0-1000mm(0-40″) K21-108 0.01mm(.0005″) ±0.07mm 1188 150 7 18
　 K21-108-1 0.01mm(.0005″) ±0.07mm 1188 200 7 18
　 K21-108-2 0.01mm(.0005″) ±0.07mm 1188 250 7 18
　 K21-108-3 0.01mm(.0005″) ±0.07mm 1188 300 7 18
