HOME>>PRODUCTS>>Digital
Caliper Series>>Digital
Thickness Gauge |
BACK>> |
| |
|
|
| |
|
 |
| Power on/off. |
| Inch/mm conversion at any position. |
| Zero-setting at any position. |
| Universal purposes with two types
of measuring faces. |
| Easy to measure the thickness
of paper,film,jewelry, cable, metal foil etc. |
| Can fast trace Max/Min value. |
| |
| |
|
| |
| Measuring Range |
Order
No |
Resolution |
Permissible Error |
Remarks |
| 0-10mm(0-.4¡å) |
B16-150 |
0.01mm(.0005¡å) |
¡À0.03mm |
30mm |
| 0-10mm(0-.4¡å) |
B16-151 |
0.01mm(.0005¡å) |
¡À0.03mm |
120mm |
| 0-10mm(0-.4¡å) |
B16-160 |
0.001mm(.00005¡å) |
¡À0.009mm |
30mm |
| 0-10mm(0-.4¡å) |
B16-161 |
0.001mm(.00005¡å) |
¡À0.009mm |
120mm |
|
|
