Digital Scale Units(Horizontal Type) |
BACK>> |
| |
|
|
| |
|
|
| Power on/off. |
| Zero-setting at any position. |
| Inch/mm conversion at any position. |
| Data output. |
| Data hold. |
| Presetting. |
| Come with two mounting brackets,each
located at either end of the scale. |
| |
|
| |
| Measuring
Range |
Order
No |
Resolution |
Permissible
Error |
A
mm |
B
mm |
C
mm |
D
mm |
E
mm |
F
mm |
G
mm |
L1
mm |
L2
mm |
| 100mm(4″) |
K12-200A |
0.01mm(.0005″) |
±0.02mm |
20 |
4 |
40 |
6 |
24 |
80 |
40 |
244 |
220 |
| 150mm(6″) |
K12-201A |
0.01mm(.0005″) |
±0.03mm |
20 |
4 |
40 |
6 |
24 |
80 |
40 |
294 |
270 |
| 200mm(8″) |
K12-202A |
0.01mm(.0005″) |
±0.03mm |
20 |
4 |
40 |
6 |
24 |
80 |
40 |
344 |
320 |
| 300mm(12″) |
K12-203A |
0.01mm(.0005″) |
±0.04mm |
20 |
4 |
40 |
6 |
24 |
80 |
40 |
444 |
420 |
| 400mm(16″) |
K12-204A |
0.01mm(.0005″) |
±0.05mm |
20 |
4 |
40 |
6 |
24 |
80 |
40 |
594 |
520 |
| 500mm(20″) |
K12-205A |
0.01mm(.0005″) |
±0.05mm |
20 |
4/5.5 |
40/45 |
6/8 |
24/32 |
80/95 |
40/51 |
682 |
620 |
| 600mm(24″) |
K12-206A |
0.01mm(.0005″) |
±0.08mm |
20 |
4/5.5 |
40/45 |
6/8 |
24/32 |
80/95 |
40/51 |
782 |
720 |
| 700mm(28″) |
K12-207A |
0.01mm(.0005″) |
±0.08mm |
24 |
5.5 |
45 |
8 |
32 |
95 |
51 |
882 |
820 |
| 800mm(32″) |
K12-208A |
0.01mm(.0005″) |
±0.08mm |
24 |
5.5 |
45 |
8 |
32 |
95 |
51 |
982 |
920 |
| 900mm(36″) |
K12-209A |
0.01mm(.0005″) |
±0.08mm |
24 |
5.5 |
45 |
8 |
32 |
95 |
51 |
1082 |
1020 |
| 1000mm(40″) |
K12-210A |
0.01mm(.0005″) |
±0.10mm |
31 |
10.5 |
60 |
10 |
40 |
95 |
51 |
1240 |
1200 |
| 1200mm(48″) |
K12-212A |
0.01mm(.0005″) |
±0.12mm |
31 |
10.5 |
60 |
10 |
40 |
95 |
51 |
1440 |
1400 |
| 1500mm(60″) |
K12-215A |
0.01mm(.0005″) |
±0.12mm |
31 |
10.5 |
60 |
10 |
40 |
95 |
51 |
1740 |
1700 |
| 2000mm(80″) |
K12-220A |
0.01mm(.0005″) |
±0.20mm |
31 |
10.5 |
60 |
10 |
40 |
95 |
51 |
2240 |
2200 |
|
|
